TH-2004L6-D
High Precision Anaerobic Thread Coating Machine With Touch Screen
Introduction
Feed system:30CC/55CC Barrel +vacuum function + s/s needle. Syringe design is adopted, Easy to replace different thread locker adhesive and replace barrel cost is low. It is the best choice for small batch production of different products and only a little glue be coating
Equipment function: Specially designed for small screw vacuum suction auxiliary device, perfect solution to the phenomenon of product falling from the fixture, precision screw slider drive, to ensure that the small screw gluing uneven problem, double driver motor design, to ensure the eccentricity of rotation and prevent product slippage, using the same coaxial movement, for the small thread of the automatic thread groove automatic glue operation in the glue more uniform, faster The movement of the nozzle is controlled by the motor.
Application
Suitable for M1-M3 of Micro-screw, bolt, nuts, Plug and various pneumatic connector, fastener thread coating;
Liquid Material: Anaerobic glue, thread locker adhesive thread;
Packing capacity: 50ml packing glue;
Specification
ITEM: TH-2004L6
Speed: 0.3-0.5S/circle of thread
Length: ≤50 mm(can adjusting)
Thread ID: Size M1 - M3
Vacuum way: vacuum suction
Start way: Panel /foot switch/touch screen
Control way: PLC+ special software version 2.0 for thread coating machine
Drive: 3 sets of Precision stepper motor
IO Signals: 1 Inputs / 1 Outputs
Input Air pressure: 5 bar (1bar =1.01972kg/cm² =14.5038psi)
Input voltage: 110/220VAC (Internal conversion)
Power: ≤120W
Temperature: 0-40℃
Working humidity: 40-60%
Weight: 19.5Kg
Size: 46*37*40（cm）
Advantage
1.The equipment developed and designed for various flat head, mushroom head, hexagon socket and other tiny screws of M1-M3 different of screw, bolt, nut, connector fastener.
2. Highly sensitive vacuum suction device effectively solves product falling in the coating process.
3. Double-drive design, the product jig and the thimble device are equipped with independent motors to rotate synchronously, which ensures better concentricity and avoids uneven coating in during rotation process.
4. Professionally designed touch screen PLC gluing control system, visual operation panel, all processing parameters can be set directly through the touch screen, such as the adjustment of gluing start and end positions and gluing length (number of turns) .
5. With external communication function, it can be connected with other devices.
6. For different Products should be processed only by changing the product jig.
7. It can be matched with different diameter needles according to the size of the workpiece teeth to achieve perfect gluing effect.
8. Equipped with a voltage stabilization control module, dispensing glue evenly, without drawing, dripping, and leaking glue.
9.Add optional for automatic unloading device , saving the time of manual unloading and no easy pick and place question.
10.The product be glued product by machine, greatly improves reliability and durability sealing.
Place of Origin: NingBo CHINA
Brand Name: TianHao Dispensing
Certification: CE
Model Number: TH-2004L6-D
Field: Industrial
Shipping Terms: EXW/FOB/C&F
Minimum order Quantity: 1 set
Packing Detail: export standard package
Delivery Time: 10 work day
Supply Ability: 500pcs/months
